Low Lift Safety Relief Valve

Keep equipment safe, prevent accidents and reduce losses.


The safety valve is selected based on equipment, fluid characteristics, operating temperature, set pressure, and discharge capacity. And also to apply various conditions, such as the use of the environment, accuracy, and stability, must be carefully evaluated.

The type of  "317"  Safety valve series we provide is characterized by regulating of pressure in valve rising and blowing-out when actuated and is a very compact and small valve, and also can be used in non-corrosive gases (air, oxygen, nitrogen, etc.), steam and liquids, such as water and oil.


View:

(SV-B27/SVP-B27) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE DE BAIXA ELEVAÇÃO (MODELO ANTIGO: S3W-A)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B27)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B29/SVP-B29) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE DE BAIXA ELEVAÇÃO (MODELO ANTIGO: S3W-LR)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B29)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-B9A/SVP-B9A) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE DE BAIXA ELEVAÇÃO

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B9A)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B9L/SVP-B9L) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE DE BAIXA ELEVAÇÃO

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS.
SEAL: PTFE (SVP-B9L)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-BS9A/SVP-BS9A) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE -ESTRUTURA DE BRONZE / DISCO SS

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: SUS304.
SEAL: PTFE (SVP-BS9A)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-BS9L/SVP-BS9L) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE -ESTRUTURA DE BRONZE / DISCO SS

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: SUS304.
SEAL: PTFE (SVP-BS9L)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-BS9DA/SVP-BS9DA)VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE DE BAIXA ELEVAÇÃO (1x2)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-BS9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B9DA/SVP-B9DA) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE DE BAIXA ELEVAÇÃO (1x2)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS. (1*2)
SEAL: PTFE (SVP-B9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-B9DL/SVP-B9DL) VÁLVULA DE ALÍVIO DE SEGURANÇA DE BRONZE DE BAIXA ELEVAÇÃO (1x2)

BRONZE SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
DISC/SEAT: FORGED BRASS. (1*2)
SEAL: PTFE (SVP-B9DL)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-S9A/SVP-S9A) ST.ST.304 VÁLVULA DE ALÍVIO DE SEGURANÇA DE BAIXA ELEVAÇÃO

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8.
SEAL: PTFE (SVP-S9A)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-S9L/SVP-S9L) VÁLVULA DE ALÍVIO DE SEGURANÇA ST.ST.304 DE BAIXA ELEVAÇÃO

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8.
SEAL: PTFE (SVP-S9L)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-S9DA/SVP-S9DA) VÁLVULA DE ALÍVIO DE SEGURANÇA ST.ST.304 DE BAIXA ELEVAÇÃO (1x2)

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-S9DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-S9DL/SVP-S9DL) VÁLVULA DE ALÍVIO DE SEGURANÇA ST.ST.304 DE BAIXA ELEVAÇÃO (1x2)

ST.ST.304 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8. (1*2)
SEAL: PTFE (SVP-S9DL)
SET P.: 0.3-10 KGS/CM2. (ALT.20K)
SIZE: 1/2”~2” (WITH LEVER)

(SV-S8DA/SVP-S8DA) VÁLVULA DE ALÍVIO DE SEGURANÇA ST.ST.316 DE BAIXA ELEVAÇÃO (1x2)

ST.ST.316 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8M. (1*2)
SEAL: PTFE (SVP-S8DA)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITHOUT LEVER)

(SV-S8DL/SVP-S8DL) VÁLVULA DE ALÍVIO DE SEGURANÇA ST.ST.316 DE BAIXA ELEVAÇÃO (1x2)

ST.ST.316 SAFETY RELIEF VALVE
SCREWED END TO BS21, ANSI B2.1
BODY/DISC/SEAT: CF8M. (1*2)
SEAL: PTFE (SVP-S8DL)
SET P.: 0.3-10 KGS/CM2. (ALT.20/30K)
SIZE: 1/2”~2” (WITH LEVER)
